XFP, 10GBase-ZR, 10.3125 Gbps, DDM, 80km

XFP, 10GBase-ZR, 10.3125 Gbps, DDM, 80km

Produktnummer: XFP-ZR Kategori:

3 614,88 kr

APPLICATIONS
• IEEE 802.3ae 10GBASE-ZR 10.3125 Gb/s
• Regional Networking
• Core Networks

FEATURES
• Compatible with XFP MSA Rev. 4.5
• Compliant to IEEE 802.3ae 10GBASE-ER at 10.3125 Gbit/s
• Up to 80 km transmission on 9/125 µm SMF G.652
• 24 dB link budget
• Hot pluggable 30 pin connector
• 1550 nm laser (EML)
• Duplex LC-connector interface
• Compliant with the EU RoHS 6 Environmental Requirements
• operating temperature 0ºC to 70ºC

Koding

Alcatel, Extreme, Fiberworks, Foundry, Huawei, Juniper, Juniper EX
Bølgelengde (nm)

1550
DDM

Ja
Fareklasse

Laser klasse 1
Formfaktor

XFP
Konnektor

LC Duplex
Lasertype

EML
Linjemodulasjon

NRZ
Max. mottakereffekt [dBm]

-7
Mediatype

Singelmodus
Mottakerfølsomhet (Rx power min.) [dBm]

-24
Mottakertype

APD
Produktklassifisering/tollkoder

ECCN: 5A991, HS: 8517.62.0090
Protokoll / bitrate

10 Gigabit Ethernet, 10G Fibre Channel, SDH STM-64
Rekkevidde (dB)

24
Rekkevidde (km)

80
Sendestyrke (Tx power) max. [dBm]

+4
Sendestyrke (Tx power) min. [dBm]

0
Temperaturområde, drift

0°C – +70°C (standard)
Temperaturområde, lagring

-40°C – +85°C
