The QSFP112 VR4 transceiver is a 400 Gbit/s pluggable module for bi-directional serial optical data communications such as 400GBASE Ethernet. The transceiver operates with four parallel data streams of 106.25 Gbps in order to provide an aggregated signaling rate of 425 Gbps. The module has an MPO 12 (Base 8) APC male connector and uses four fiber pairs to create the four data lanes.
The module is fully compliant with all QSFP112 related MSA standards and Digital Diagnostic functions are available through an I2C interface. QSFP112-VR4 complies with IEEE 802.3 and 400Gbase-VR4.
APPLICATIONS
• 400G Ethernet
• NDR Infiniband
• Data Center and LAN
FEATURES
• Compliant with 400Gbase-VR4
• 4x Single Lambda 850 nm
• Up to 106.25 Gbps Data rate per wavelength
• Up to 50m transmission on OM4
• Electrically hot-pluggable
• Digital Diagnostics Monitoring Interface
• Compliant with QSFP112 MSA
• Compliant with OIF-CMIS rev.5.0
• Dual MPO 8/12 APC connector
• Case operating temperature range:0°C to 70°C
• Power dissipation < 9 W
