Hjem/Produkter/Transceiver/QSFP+/QSFP+, 40GBASE-SR4, 150m, I-Temp
QSFP+, 40GBASE-SR4, 150m, I-Temp

QSFP+, 40GBASE-SR4, 150m, I-Temp

Produktnummer: QSFP-40G-SR4-RGD Kategori:

684,75 kr

APPLICATIONS
• 40G Ethernet
• Infiniband QDR
• Fiber channel


FEATURES
• High Channel Capacity: 40 Gbps per module
• Up to 11.1Gbps Data rate per channel
• Maximum link length of 100m links on OM3 multimode fiber or 150m on OM4 multimode fiber
• High Reliability 850nm VCSEL technology
• Electrically hot-pluggable
• Compliant with QSFP+ MSA
• Industrial case operating temperature range: -40°C to 85°C
• Power dissipation < 1.5 W

Koding

Alcatel, Arista, Cisco, Citrix Netscaler, Dell, Extreme, Fiberworks, Fortinet, HP Virtual Connect, Huawei, IBM, Infinera XTM, Intel, Juniper, Mellanox
Bølgelengde (nm)

850
DDM

Ja
Fareklasse

Laser klasse 1
Formfaktor

QSFP+
Konnektor

MPO
Lasertype

VCSEL
Linjemodulasjon

NRZ
Mediatype

Multimodus
Mottakertype

PIN
Produktklassifisering/tollkoder

ECCN: 5A991, HS: 8517.62.0090
Protokoll / bitrate

10 Gigabit Ethernet, 40 Gigabit Ethernet
Rekkevidde (dB)

2
Rekkevidde (km)

0, 150
Temperaturområde, drift

-40°C – +85°C (industriell)
Temperaturområde, lagring

-40°C – +85°C
