APPLICATIONS• 40G Ethernet• Data Center and LANFEATURES• 4 CWDM lanes Mux/Demux design (1271, 1291, 1311 and 1331 nm)• Up to 11.1Gbps Data rate per wavelength• Up to 150m transmission on OM3 MMF• Up to 2km transmission on SMF• Electrically hot-pluggable• Digital Diagnostics Monitoring Interface• Compliant with QSFP+ MSA with LC connector• Case operating temperature range:0°C to 70°C• Power dissipation < 3.5 W
QSFP+, 40GBASE-LX4, 4 x 10.3 Gbps, 2km
APPLICATIONS• 40G Ethernet• Data Center and LANFEATURES• 4 CWDM lanes Mux/Demux design (1271, 1291, 1311 and 1331 nm)• Up to 11.1Gbps Data rate per wavelength• Up to 150m transmission on OM3 MMF• Up to 2km transmission on SMF• Electrically hot-pluggable• Digital Diagnostics Monitoring Interface• Compliant with QSFP+ MSA with LC connector• Case operating temperature range:0°C to 70°C• Power dissipation < 3.5 W
På lager
2 827,00 kr
| Koding | H3C |
|---|---|
| Bølgelengde (nm) | 13104x CWDM (1270-1330) |
| DDM | Ja |
| Fareklasse | Laser klasse 1 |
| Formfaktor | QSFP+ |
| Koding | H3C |
| Konnektor | LC Duplex |
| Lasertype | DFB |
| Linjemodulasjon | NRZ |
| Max. mottakereffekt [dBm] | +3 |
| Mediatype | SingelmodusMultimodus |
| Mottakerfølsomhet (Rx power min.) [dBm] | -11 |
| Mottakertype | PIN |
| Produktklassifisering/tollkoder | ECCN: 5A991HS: 8517.62.0090 |
| Protokoll / bitrate | 40 Gigabit Ethernet |
| Rekkevidde (dB) | 5 |
| Rekkevidde (km) | 2 |
| Sendestyrke (Tx power) max. [dBm] | +2 |
| Sendestyrke (Tx power) min. [dBm] | -6 |
| Temperaturområde, drift | 0°C – +70°C (standard) |
| Temperaturområde, lagring | -40°C – +85°C |
